Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 499
the pointing chuck, into which chuck the wire enters,previous to a portion of it being cut off to form a pia A steel cutter 18 is fitted into a groove orsocket in the cutter-stock 19, so as to admit of its being adjusted and fixed therein by screws, and tccause the cutting edge of said cutter to… … A small projection or plate 19c extending from the edge of the arm 19(/ of said lever rests upon theperiphery of the cutter-cam b, and a stud standing ou^ater.ally from said arm 19<^ at right angles tcthe plane of its motion on its centre 22, rests against the side of said cara i, on which side…
