Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 728
Fig. 3414 is an end elevation, showing the arrangement for the geers and belts for driving the rollsand lifting motion for the rails. Fig. 3415 is a front elevation, showing the rolls, spindles, and an edge view of the friction-disks aafor driving the spindles. These disks and the •whirls running…
Mechanical engineering · Mechanics · Engineering
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
