cams acting on a series of leverscontrolling the lifter plate was adopted (fig. 138). The bolster rail wassupported on rods coming up from a lever extending horizontallyacross the whole frame, its ends being held by another lever crossingthe end of the frame. This lever hung on a pin in the cross… … Fig. 138.—End View of Common Throstle A, A, Gearing of drawing rollers. B, Driver of drawing rollers,c, Tin cylinder driving the spindles. D, Pinion of lifter cam.E, Heart-shaped cam acting on lifter plates. F, Bobbin creel. EVOLUTION OF SPINNING MACHINERY 71 into which a worm on the end of a…
