nut-tapping end, and Fig. 3470 is a similar view of the bolt-screwing end. The frame-work of the ma-chine A A, and the sole-plate B B, are cast in one piece. The driving-cone C is supprted by the up-right frames near the centre of the macliine, and carries a pinion D, of 15 teeth, which geers with…
