nough to make them sufficiently large—they can be made stronger or.account of their form; they have, also, more steam and water room. The boiler of a first-class locomo-tive of ordinary construction will generate enough steam, when the fire is in full operation, to fill thesteam space in four… … The smoke and gases from the furnace are conveyed through the smoke-flue D, Figs. SioO and 3731,within the heating chamber A, until it is opposite the extracting shaft E; from here it is conductedacross and into the cast-iron chimney P, within the extracting shaft E. The smoke-ttue within the…
