in boxes of thiskind is always liable to occur, because of the differencein thicknesses at D and E. In Figs. 27-31, common constructional joints ofanother type are shown. These are termed half lapjoints, or halvings. They are used on all thin, openframings for base plates, engine beds, vertical… … Fig. 27. Example of Framed Work.
