ultant moment, will, when measured with the forcescale, give the magnitude of S. Having found S, the force P may be found in like manner by takingmoments about another point in the bar B (say at the intersection of Band C). Lastly, the force Q may be determined by taking momentsabout a point… … FIG. 268. and a funicular polygon, the latter having one angular point at O, asexplained in the latter part of Art. 57, p. 38. 182. The Three-Hinged Arch.—If the ends of a roof or bridge trussare secured to foundations by hinged joints, and there is another hingedjoint at an intermediatepoint, say,…
