ample will showthe relation between the space andtime averages of the .pressure in aparticular case. ABCD (Fig. 447) isthe force-space diagram on a base AB,which represents the stroke of thepiston (20 inches). The steam pressureis 150 Ibs. per square inch for thefirst 4 inches of the stroke, after… … r~~ A1 0FIG. 447. a(space)P . . 1150 3150 5 120 785-71 966-67 11 54-55 1346-15 1540 1735-29 1931-58 from which the mean value of P is 78*0, and this is the space averageof P. To find the time average of P, construct the semicircle A9B, whichrepresents the path of the crank pin for one stroke of the…
