Audsley, W. (William), 1833-1907, Audsley, George Ashdown, 1838-1925 · London ; Glasgow ; Edinburgh : William Mackenzie · leaf 450
G ORDERS OF ARCHITECTURE. equal to cb; draw b e at right angles to be, and de at right angles to c d, fromthe point, e, as a centre, describe the arc, b d; this completes the contour of themoulding, b d f. These are the simple Roman forms of the conge. It is obvious that the curvemay be varied into…
Architecture, Domestic · Architecture, Gothic
Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
