e diagrams for the piston are the same as those shownin Fig. 461, p. 297. The polar velocity diagram becomes a circledescribed on the crank as diameter when the latter is perpendicular to theline of stroke. The arrangement shown in Fig. 468 is the equivalent of an infiniteconnecting-rod.… … FIG. 468. FIG. 469. slotted piece KL to pass. If the slotted piecehave two slots at right angles, as shown in Fig. 4G9, the crank may beplaced anywhere on the shaft without altering the shaft in any way. 261. Piston or Slider Acceleration. — Since CD (Figs. 467 and470) represents the. piston…
