ding tumblerMN permanently gears with K, and by lifting and sliding MN the wheelL may be made to engage with any one of the wheels (), P, Q, 11, or S,which are all firmly keyed to the shaft H, or L may be placed clear ofthese wheels. When the shaft II is driven through the tumbler gear itrotates… … -pIG WHEEL TRAINS 391 due to throwing the tumbler gear in is diminished. The particularexample illustrated in Fig. 609 is from a radial drilling machine by theBickford Drill and Tool Co. of Cincinnati. The gear shown is placed onthe base of the machine, and the shaft H drives a vertical shaft in…
