gram of pressures. Because, 0 is the intersection of twoof flic forces or pressures ; therefore, the direction of thethird force must pass through 0 ; but this third force mustalso pass through B. Hence it follows, that 0 B is thedirection of the pressure upon the hinge, and in like man-ner 0 e,… … CONSTRUCTION. On the line D N, mark off D n equal to the units of 104 PRACTTOAL MECHANICS. weight ill W, draw 7i7n parallel to DA, intersecting D 0m m, and from m draw m e, parallel to B n ; then Bnmewill be the parallelogram of pressures ; therefore, the unitsm De will give the tension of the…
