Architect and engineer (1905)

San Francisco : Architect and Engineer, Inc · leaf 73

An illustration from Architect and engineer, 1905, leaf 73 — BASEMENT FLOOR PLAN FIRST FLOOR PLAN FEBRUARY, 1949 THE MIHRDR BUILDING . . . … I-OFFICE 2-CORRIDOR 3-WOMENS TOILET A -womens locker rm. 5-MENS toilet fe-MENS LOCKER RM 7-FAN ROOM 6-REST ROOM 9-JANITORS STORAGE lu-TOILET I l-LOCKE R ROOM l?-SWITCHBOARD RM. 13- TELEPHONE EQUIP RM. I4-SE0VICE COPRIDOR IS-ELEVATOR LOBBY I6-CIRCULATIONDEPARTMENT 17-WORK SPACE FOURTH FLOOR PLAN

Architecture · Building
