, the usualwood soffit was eliminated and in addition, no shoreswere required under the joists. The pans themselvesspan 13 feet, 1 inch, and the only shoring requiredis under the girders and bridging. The framing wasarranged to make possible a maximum reuse of thesepans on all floors. This system… … Manufactured aiInstalled by THE FINK & SCHINDLER CO. Since IB82552 Brannan Street San Francisco, Calif. EXbrook 2-1513 The typical girder is 54 inches wide by 23 inchesdeep. This shape girder was chosen to reduce thefloor-to-floor heights resulting in a saving in excava-tion and total wall…
