onsiderable turbulence is produced, sub-stantially adding to the resistance of the vent. Ac-tually an elbow would work much better than a Tee. When you consider the outstanding advances madeby the gas industry in production, distribution, ap-pliance design and safety controls, its rather… … Fig. 4: Showing how condensate inside of open glass teetraps flow of vent gasses. ZONE WHERE MOISTURE FROM FlUE GASES CONDENSES ON COLD GLASS
