Architectural drawing : a textbook that combines the parctical instructions and examples that the student needs, with the suggestive programs, supplementary problems, etc, required by the teacher, written by an architect of wide experience who has also taught the subject for years at Teachers' College, Columbia University, and Mechanics' Institute, New York (1920)
Teale, Oscar S · New York : U.P.C. Book · leaf 47
poses and a majorityof times the legs of a compass are simply opened tothe desired distance (radius) and the curve sweptwith the legs of compass in normal position, Fig. 33. Draw circles, or arcs of circles first, or at least, theyshould be drawn first in the process of inking. It isnot always… … ♦See Fig. 32. TOOLS—IN PRACTICE 45 impossible to successfully join a curved line to astraight line. When a number of circles or arcs of circles are tobe drawn consecutively (concentric), the smaller oneshould be drawn first and each circle or arc added bygradually increasing the radii, by spacing…
Architectural drawing
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
