Architectural engineering. With special reference to high building construction, including many examples of Chicago office buildings (1895)
Freitag, Joseph Kendall · New York, J. Wiley & sons; [etc., etc.] · leaf 120
main spandrel supports,is shown in Fig. 52, which is a sectiontaken from near the corner of the Re-liance Building. The connections ofthese plate girders to the Gray columnsused, are shown in Fig. 104, Chapter VII.The connections of the cast uprightsto support the terra-cotta mullions be-tween the… … 102 ARCHITECTURAL ENGINEERING. or sidewalk level, and shows the prismatic lights in thesidewalk, as well as the small windows which help to lightthe basement restaurant space. Fig. 57 is a section takenat the attic floor, showing the main cornice and roof con-struction. The materials generally used…
Building, Iron and steel
