Architectural engineering. With special reference to high building construction, including many examples of Chicago office buildings (1895)
Freitag, Joseph Kendall · New York, J. Wiley & sons; [etc., etc.] · leaf 129
Fig. 64. supporting member is a floor-beam or floor-girder, as inFig. 63, taken through a bay window of the Masonic IIO ARCHITECTURAL ENGINEERING. Temple, the girder should be rigidly connected to thefloor system, to prevent any twisting tendency due to theweight of the bay. This is accomplished,… … mentioned figure, by means of the top and bottom tie-plates shown. Fig. 64 shows a section at the bottom of a bay windowin the Masonic Temple. Fig. 65 shows a half plan of the metal framing for theState Street bay window in the Reliance Building.
Building, Iron and steel
