Architectural iron and steel : and its application in the construction of buildings, including beams and girders in floor construction, rolled iron struts, wrought and cast-iron columns, fire-proof columns, column connections, cast-iron lintels, roof trusses, stairways, elevator enclosures, ornamental iron, floor lights, and skylights, vault lights, doors, and shutters, window guards and grilles, etc., etc., with specification of ironwork and selected papers in relation to ironwork, from a revision of the present law before the legislature affecting public interests in the city of New York, in so far as the same regulates the construction of buildings in said city, tables selected expressly for this work, of the properties of beams, channels, tees and angles, used as beams, struts and columns, weights of iron and steel bars, capacity of tanks, areas of circles, weights of circular and square cast-iron columns, weights of substances, tables of squares, cubes, etc., weights of sheet copper, brass and iron, etc (1892)

Birkmire, Wm. H. (William Harvey), 1860-1924 · New York Wiley · leaf 153

An illustration from Architectural iron and steel : and its application in the construction of buildings, including beams and girders in floor construction, rolled iron struts, wrought and cast-iron columns, fire-proof columns, column connections, cast-iron lintels, roof trusses, stairways, elevator enclosures, ornamental iron, floor lights, and skylights, vault lights, doors, and shutters, window guards and grilles, etc., etc., with specification of ironwork and selected papers in relation to ironwork, from a revision of the present law before the legislature affecting public interests in the city of New York, in so far as the same regulates the construction of buildings in said city, tables selected expressly for this work, of the properties of beams, channels, tees and angles, used as beams, struts and columns, weights of iron and steel bars, capacity of tanks, areas of circles, weights of circular and square cast-iron columns, weights of substances, tables of squares, cubes, etc., weights of sheet copper, brass and iron, etc, 1892, leaf 153
ors are securedon the inside to ladder by a padlock or chain and padlock. 200. Scuttle Ladder—is placed at the entrance to scuttle,and is made of 3 X ^-inch flat iron, for the sides, and ^-inchdouble rungs, 12 inches in rise. The width of ladder 20inches from outside to outside of sides. To be… … i6 sheet iron. The lower door is fastened to curb by an angle-iron frame i^ X i^ X i inch thick. 201. Iron Fronts.—Cast-iron for fronts has many advan-tages in its favor—strength, lightness of structure, facility oferection, durability, economy and incombustibility. Previousto their erection in the…

Building, Iron and steel · Building · Ironwork

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
