Fig. 35. cement filling is used, embedding the straps and girders.If the beams are of considerable depth, the soffit of thearch may show the panelled beams, as in Fig. 36. The HOOK … mm 5 G^SPIPEWIRE: NETTING Fig. 36. upper layer of cement may be laid in colored geometricalpatterns, or, if a wood floor is used, this upper layer of cementis made but 1 in thickness, with nailing-strips embedded. The following table gives data from two of the build-ings before mentioned :…
