o give them stiffness a verticalflange is cast on the back. The railing is constructed as shownby the connection D, with the baluster curved to clear thetread at C. The top rail is composed of a flat bar with a half-roundbar of wrought iron riveted on top. These stairs can be adapted STAIR WA VS.… … PLAN W/MSS//MS/////)///////////}///y//////}w The treads to be cast iron, open-diamond pattern.Wooden treads are often used by securing them to the angleknee clippings {A) with carriage bolts. 76 ARCHITECTURAL IRON AND STEEL. 131. Circular Stairs—are used where circumstances pre-vent the…
