twisted in a machine, and completed in aboutfifteen seconds, in one heat, without hammering. They are ofuniform strength and fitted to beams. The following sizesare commonly used: CHIMNEY CAP. 141 Size of Beam. 4 X 10 X 44 X 12 X 44 X 14 X 46 X 10 X 46 X 10 X 66^ X 12 X 4 Size of Iron 2 xr 2 xr 2… … 142 ARCHITECTURAL IRON AND STEEL. 2i8. Chimney Cap.—This cap is made of cast iron, \ inchthick if small and f inch thick if the chimney is larger than 4feet square. The outer lip of cap projects down, completelycovering the upper layers of brickwork and protecting themortar joints from the action…
