A QUIRKED OVOLO. (Fig. 7.) Divide the height into four equalparts; with one point on C describe thearc C D ; on C with the distance A B,describe an arc cutting the former at D.Through D and C draw the line D C F,cutting the small circle at F ; then witha radius D F, describe the arc F B, andit will… … Describe the smaller circle as in thelast; and through its centre and theend B of the fillet draw the line C B E,taking E according as you intend tohave the under part of the moldingflatter or quicker. Take the distanceE C, and on B describe an arc at D,then take the distance E A that is [E Cmade…
