Klenke, William Walter, 1888- [from old catalog] · Peoria, Ill., The Manual arts press · leaf 19
Fig. 7. will be seen to form. To remove this burr, rub the slip on that side several times, then repeat the entire whetting operation until the gouge has been properly sharpened. The grinding of the skew is somewhat different from that of the other tools, in that this tool has a bevel on both… … Fig. 8. Whetting a Skew Chisel. rect position of the skew while being ground; i.e. the cutting edgeis kept parallel with the top of the stone.. In whetting the skew thesame principle is carried out, Figs. 7 and 8. All scraping tools are ground only on one side. The foregoinginstructions hold good…
Woodwork (Manual training)
