is a front elevation of the common draw loom. The frame AA iscalled the carriage, fi-ora its use in supporting the harness ; and restson the capes of the loom, which are seen in section at A^A^ Onthe top of this frame is fixed the pulley box E^ which contains the 144 THE ART OF WEAVING. pulleys… … is placed in a slanting position sufficient to aUow the tail cords BBto sink m opening the sheds, without olistniction from the frame orpulleys below. The harness is composed of the following parts; namely, theneck t^\*ines, wliich extend from the neck of the harness, as pomtedout by the figures of…
