is a front elevation of the common draw loom. The frame AA iscalled the carriage, from its iise in supportin g the harness; and restson the capes of the loom, which are seen in section at A^A^ Onthe top of this frame is fixed the puUey box E*^ which contains the 144 THE ART OF WEAVING. pulleys over… … is placed in a slanting position sufficient to allow the tail cords BBto sink in opening the sheds, without obstruction from the frame orpulleys below. The harness is composed of the following parts; namely, theneck twines, which extend from the neck of the harness, as pointedout by the figures of…
