We would here remark, that in describing the drawings just al-luded to, the same letters of reference indicate similar parts in all ofthem. A A, Fig. 95, is the frame of the machine, connected bysuitable cross bars at B B B B; the two upright posts C C, one at 194 THE ART OF WEAVING. each end of… … are shown in Fig. 93: into these are inserted the pointed screwsF F. wliich are fastened by means of the thumb screws G G; thesebeing brought against the cross pieces E E after the screw points JACaUARD MACHINE. 195 H H have been inserted into small brass or steel bushes on the sidesof the cylinder…
