Practical instructor and reference book for locomotive firemen and engineers: a practical treatise .. (1916)
Lockhart, Charles F. (Charles Fulton), b. 1872 · New York, The Norman W. Henley publishing co. · leaf 74
essentially a part of thisgear, although it may be used in connection with it ifdesired. THE WALSCHAERT VALVE GEAR (Fig. 9) The Walschaert valve gear, which is coming intogeneral use, having been adopted as the standard by anumber of roads in this country, has been in use for anumber of years in… … O o 72 WALSCHAERT VALVE GEAR open to the view where all of its parts can be readily seenand its defects discovered. It is light, accurate, anddurable. The cost of repairs is much less than the oldstyles of valve gears. 243. Its parts, their names, and relations to each otherin controlling the…
Locomotives
