The art of weaving, by hand and by power, with an introductory account of its rise and progress in ancient and modern times (1844)
Gilroy, Clinton G · New York, Baldwin · leaf 355
also operates upon the rod DDat P, Fig. 150, and shifts it to the right hand, until the point C ofthe lever B C, drops into the square groove seen in Fig. 150 : thelever or catch C, is kept in the groove of the rod D D, by thesmall spiral spring Q,. Thus by pulling forward the rail H H,… … Fig. 154. Drop wire of one fourth the working size. WARPING. 337 Fig. 1.52 is a front view of the guide reed E, seen in Fig. 151, fordirecting the yarn on the beam F : it consists of a piece of sheetiron cut into a number of shts, corresponding to the number ofthreads to be warped on the beam. By…
Weaving
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
