The art of weaving, by hand and by power, with an introductory account of its rise and progress in ancient and modern times (1844)
Gilroy, Clinton G · New York, Baldwin · leaf 91
76 THE ART OF WEAVING. Fig. 7, may be considered either as a profile elevation, or as aprofile section of the same loom. All the parts in Fig. 7, are represented as they appear to a personstanding at one side of the loom, and many parts, concealed or cutaway in Fig. 6, are seen very plainly in Fig.… … Fig. 8, is a transverse section of the same loom, as viewed fromthe front: the cloth roll, the lay, and all the other parts in front of PLAIN WEAVING. 77 the headles, are taken away that the mounting contained in thefigure may be seen. The lay and reed, which are left out of Fig. 8,are distinctly…
