Gilroy, Clinton G · New York, G. D. Baldwin · leaf 165
without obstruction from the frame orpulleys below. The harness is composed of the following parts; namely, theneck twines, which extend from the neck of the harness, as pointedout by the figures of reference 1, 2, 3, 4, 5, 6, 7, 8, 9 and 10, to theknots at EE ; the sleepers,* which connect the… … * The name usually given to that part of the cords or mountings whichpasses through the board CC, commencing at the knots EE, and ending atthe mails DD. DRAW LOOM. 145 th^ twines, that connect the maus and leads or weights at XX,called hangers, to sink the maus after they have been raised to…
Weaving
