rdingly.The axis of the yarn beam rests on two slots of the framing at K,and is pressed down upon the drum J, by the stirrup L L, which isalso weighted down by the cross lever M. From the top of the 334 THE ART OF WEAVING. stiiTup L, an arm N extends to the giiide reed E, so tliat as tlieyarn fills… … the yarn beam: O, Fig. 151, is a strap attached to the weight P,and which winds round a small shaft, on the end of which theratchet wheel Q, is made fast. When the beam is sufRciently füll,the strap O is wound up by means of a wrench attached to theratchet wheel, which thereby Ufts the weight P,…
