Gilroy, Clinton G · New York, G. D. Baldwin · leaf 476
lifting and de-pressing the shuttle boxes, to or from the level of the shuttle-race inthe lay, in those looms where two or more quahties, kindsor coloursof weft, are to be employed; thirdly, in a certain and effective modeof raising the griff of the Jacquard machine in all such looms FIGURED… … 440 THE ART OP WEAVING. exhausted in the shuttle, or when the taking up of the clothupon the cloth roUer is not equal to its production ; such motion be-ing governed by the ordinary beat or Vibration of the lay. Fig. 212, represents a front elevation of the improved power loom;Fig. 213, a side…
Weaving
