The art of weaving, by hand and by power, : with an introductory account of its rise and progress in ancient and modern times. For the use of manufacturers and others. (1844)

Gilroy, Clinton G · New York: : George D. Baldwin · leaf 386

An illustration from The art of weaving, by hand and by power, : with an introductory account of its rise and progress in ancient and modern times. For the use of manufacturers and others., 1844, leaf 386 — ication, shown inFigs. 170 and 171, the real character of the infringement will bemanifest. In the first place, Mr. Stones invention consists, in the * The whip roll N, in connexion with the lever O, for the purpose hereinexplained, is not the invention of Mr. Potter, Mr. Louis Schwabe and… … application of the lever Q,, in connexion with the rod S, having thebent arm X made fast to it, the click W, ratchet wheels U, and Y,vertical shaft T, and the worm working into the spur wheel A A,on the end of the yarn beam (see Figs. 165 and 166 ;) and theseparts, receiving motion from the…

Weaving

Internet Archive · Clark Art Institute Library · Public Domain Mark 1.0. Free to use for anything.
