The art of weaving, by hand and by power, with an introductory account of its rise and progress in ancient and modern times (1844)
Gilroy, Clinton G · New York, Baldwin · leaf 388
, a lever, extending downnearly as low as the bottom of the lay sword; D, the part of thelay in which the bar F, slides; F, a perpendicular shaft, having aratchet wheel G, at its lower end, and an endless screw or worm H,on its upper end which operates, by gearing, to give the requisitemotion to… … The following is the manner in which the bar E, receives its mo-tion from the spring reed B :— When the lay advances and brings the reed into contact with the * This alteration of Stones loom, notwithstanding its similarity to the ori-ginal, was made the subject of a patent by one Welcome A.…
Weaving
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
