Automobile driving self-taught; an exhaustive treatise on the operation, management and care of motor cars (1912)
Russell, Thomas Herbert, 1862-1947 · Chicago, Charles C. Thompson co. · leaf 245
aft, or, (3) Through the magneto or pump shafts, and thence through thetiming gears to the crank-shaft. In addition to the above Is the U. S. L. system in which the motor-generator Is mounted directly on the crank-shaft in place of the usualfly-wheel. This is the simplest type of all since It… … AUTOMOBILE DRIVING 243 When the drive is through the fly-wheel, with independent motor(M) and generator (G) as shown in Fig. 1, the motor end is cut inand out of service by throwing a pinion (A) in or out of mesh withthe teeth cut in the circumference of the fly-wheel (F) by means ofthe starting…
Automobiles
Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
