Information; elementary electricity, motor car electric systems, the gas engine from an ignition point of view, driving the car (1920)
Phillips, Harvey Elmer, 1874-1948 · Dayton, Ohio, Auto Electric Systems Publishing Company · leaf 265
he magneto will thenoperate. Also remove the commutator cover on the magneto, in case the troubleshould be there. 262 INFORMATION Dual System. The care of the magneto is the same as the independent systems, but the mag-neto commutator must be wired strictly in accordance with diagrams, as it will… … Fig. 23. SU4 Clockwise Magneto WIRING DIAGRAMS TYPE SU6
Automobiles
Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
