Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)
Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 320
aft is placed at anangle with the other shaft sections, fig. i8o, and one in whichthe several parts are in hne, as in fig. i8i. THE DRIVE 293 Ques. What name is given to the latter?Ans. The straight line drive. Ques, What are its advantages? Ans. It reduces friction and v^^ear due to the… … Figs. 180 and 181.—Diagrams to illustrate different constructions of shaftdrive. The upper figure shows the ordinary construction, in which the rearshaft length is at an angle with the engine shaft. The lower figure illustratesthe straight line drive in which the several shaft lengths are placed in…
Automobiles
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
