Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)

Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 85

An illustration from Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles, 1906, leaf 85 — -elliptical single spring running transversely over the forward 72 SELF-PROPELLED VEHICLES. shaft. The accompanying diagram plan of the Duryea three-wheeled carriage and the view of a four-wheeler display the con-structional points to advantage. As we shall see later these arethe same in both,… … Fig. 69.—Angle Iron Underframe of the Knox Three-wheeled Gasoline Phaeton, showingmotor and gearing in position, also steering connections. in favor of using three-wheelers. One of the most prom-inent constructional considerations is that the principle ofthree-point support largely, if not…

Automobiles

Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
