Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)
Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 329
ide of the 302 A UDELS ANSWERS sprocket. These gear wheels, last mentioned, are rigidlyattached on either side to the inner ends of the centerdivided axle bar, one serving to turn the left wheel, the otherthe right. When power is applied to the sprocket, causingthe vehicle to move straight forward,… … Figs. 189 aud 190.—Bevel gear differential. The sprocket gear carriesthree bevel pinions set on studs on three of its radii. These pinions meshwith bevel wheels on either side, which wheels are attached at the two innerends of the divided axle shaft. kind of lock or clutch to secure uniform and…
