Weaving calculations : a guide to calculations relating to cotton yarn and cloth and all processes of cotton weaving (1893)
Brooks, C. P. (Christopher Parkinson), 1866-1909 · London ; New York : E. & F. Spon · leaf 96
n from a pawl, worked by one of the slay swords. LOOM CALCULATIONS. 91 On the same stud is the change wheel. This gears withthe stud wheel, 100 teeth, firmly connected with thepinion of 12 teeth, driving the beam wheel 75- Thebeam or sand roller is 15 inches in circumference, and iscovered with… … Fig- 5- changes of picks in the cloth, a larger wheel giving fewerpicks in the quarter inch. Each gear has a constantnumber associated with it, called a dividend. To ascertain the Number of Picks in a QuarterInch of cloth. If the number of teeth in the change wheel be dividedinto this dividend, it…
Cotton weaving · Cotton manufacture
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
