Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)
Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 395
n an oil reservoir is shown and in the right hand half of thebase is seen the little window through which the oil level can be observed. 368 A UDELS ANSWERS Ques. What kind of primary circuit is used?Ans. A ground circuit, in which the engine and frameform the ground return. Ques. Describe the form… … Fig. 275.—Diagram of battery and coil connections for jump spark igni-tion as applied to a motor cycle. Coils are usually plainly labeled with theabbreviations: Bat., Pri., Sec, indicating that the wires are to beconnected to the battery, the primary circuit or contact maker, and the sparkplug. The…
Automobiles
