Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)
Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 419
Fig. 294.—Diagram illustrating the directions of the current in the fieldwindings and the induced current, as found in magnets, solenoids and dynamooperation. … Fig. 295.—Diagram of a dynamo electrical generator, arranged for produc-ing an alternating current, showing the constructional and operative features.Here N and S are the positive and negative poles of the field magnets, betweenwhich the lines of force are shown by the dotted lines. A ^s the…
Automobiles
