The Weeoer muffler is aented muffler of the form sho^vniji the figure. The exhaust entersthe muffler at the head, 0. Inthib head are many small diverg-ing tubes in which the gasesexpand. The gases then enter the converging tubes, B, which areset in the head, D. The 7 1/2 X 13 l/2 Weeber muffler is… … The Corbln Muffler. The mffler used on the Corbln automobil^ is of theconcentric chamber type, the outer cylinder being 5 by 24.The inlet to the imffler is a 1 cast iron iipe and the exhaustfrom the muffler is through the same size of pipe.If V is the volume of muffler in cubic inches,V is the…
