An illustration from Automotive industries, 1899, leaf 838
st the tendency of the chassisto rebound off the springs when traveling over a roughsurface. These spring studs, thus tying together thechassis and the axle, are free in their seats within limitsfixed by the torque resisting devices. Referring to the drawing, the forward torque member,supported in…
