secured to the chassis frame by onlyfour bolts, after the motor passes the testing floor. The motorpiping is one straight mixture passage from the carburetter toboth cylinders, and one straight exhaust pipe from both cylindersto the muffler. Two of the copper oil-leads go to the cylinders, while… … Fig. 249.—Section of the Ford Motor, showing positively operated inletvalves. ceases when the crank chamber pressure is dissipated by thestoppage of the motor. This four-lead oiler is from original de-signs, and has a large capacity, giving four independently regu-lated lines of lubrication,…
