Aviation engines; design--construction--operation and repair; a complete, practical treatise outlining clearly the elemtns of internal combustion engineering with special reference to the design, construction, operation and repair of airplane power plants; also the auxiliary engine systems, such as lubrication, carburetion, ignition and cooling. It includes complete instructions for engine repairing and sytematic location of troubles, tool equipment and use of tools, also outlines with the latest mechanical processes (1918)

Pagé, Victor Wilfred, 1885-1947 · New York : The Norman W. Henley publishing company · leaf 186

An illustration from Aviation engines; design--construction--operation and repair; a complete, practical treatise outlining clearly the elemtns of internal combustion engineering with special reference to the design, construction, operation and repair of airplane power plants; also the auxiliary engine systems, such as lubrication, carburetion, ignition and cooling. It includes complete instructions for engine repairing and sytematic location of troubles, tool equipment and use of tools, also outlines with the latest mechanical processes, 1918, leaf 186
Distributor Brush Carrier, Nothing could be simpler than Dixie con-struction. By loosening nuts and turningclamps aside, the distributor block can beremoved and distributor disc liftedout of its housing. TensionWinding After removing the cover themagnets can be taken off-exposingthe high iension… … Condenser. By taking out four screws the con-denser and high tension windingcan be readily removed. AG.H»SSTROM N.1 Fig. 69.—Suggestions for Adjusting and Dismantling Dixie Magneto. A—Screw Driver Adjusts Contact Points. B—Distributor Block Removed.C—Taking off Magnets. D—Showing How Easily…

Airplanes -- Motors
