Aviation engines; design--construction--operation and repair; (1919)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley publishing co. · leaf 478
ction rings bored with six holes—511^ degrees apart to take the six other connectingrods. The cage of the main connecting rod carries twoball races, one on either side, fitting onto the crank-pinand receiving the thrust of the seven connecting rods.The auxiliary connecting rods are secured in… … ja/iaaojj Jo aW o % uoo E B oo H M -d .2 •fto iB o aw/7 tel^d 480 Aviation Engines necting rods, than for the longer main rods; this does notappear to have any influence on the running of the motor. Coming to the manner in which the earliest design ex-haust valves are operated on the old style…
Airplanes
