48i. STRAIGHT LINE LINK-AGE.—With the joints S and P^ fixed the joint B will have a ver-trical motion while the link L, Mwill have a horizontal motion paral-lel with the fixed points S, P. LinksP, C, C, M, and B, C, are of equallength. L, B and L, M of equal lengths, as are the short links, S, L… … 487. THE LEVER AND ITSOFFICE in the pulley governor.Type of the Shepherd governor, inwhich centrifugal force and inertiaare combined for regulating speed. 48i^. THE LEVER AND ITSOFFICE in the pulley governor.Type of the Fitchburgh Steam En-gine Company. The lever weightsW, W are thrown out by…
