Aviation engines; design--construction--operation and repair; (1919)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley publishing co. · leaf 503
case which meshes with 16-tooth pinionon armature. The magneto turns at 2.25 times crank-case speed. Two cams, one for inlet, one for exhaust,are mounted on a carrying member and act on ninerocker arms which are capable of giving a push-and-pull 504 Aviation Engines motion to the valve-actuating… … Bottom DeadCenter Fig. 223.—Diagram Showing Positions of Piston in Le Rhone Rotary Cylinder Motor. relation to the other. These give the nine fulcrumedlevers the proper motion to open the inlet and exhaustvalves at the proper time. The cams are driven at4%o or %o of the motor speed. The cylinder…
